B-11
Welding
GLC 353/503/553 MC3
B2 Welding
B2 Welding
Hereafter please find the operating instructions for the five welding processes.
Please note the following three important instructions:
Operation of selector keys:
Example: You want to select the operation mode. The basic setting is
"operation mode 4 cycle" which is indicated by the
LED. By momentarily pressing the
selector key operation mode the next operation mode is switched on etc.
If the last operation mode is indicated and the key is pressed again, the
display jumps back to the first operation mode.
Flashing of LEDs:
The LEDs flash up in accordance with the combination of
selected values on the operation panel characteristic curve
selection.
This flashing signals that there is no characteristic curve
available for this setting. In our example, the values
Steel
and
Argon
have been set. There is no characteristic curve for a
combination of these values because welding is not possible
with this setting.
Select mode manual:
For the following explanations it is required to set the power
source to mode manual.
Please proceed as follows:
When a number appears on display panel 3, press the key
Down until two Minus signs light up.
Mode manual is switched on now.
