L-31
Elektr. und mech. Beschreibung / electr. and mech.
description / description méc. et électr. GLC 353/503/553 MC3
Elektrische Stückliste - Schalt.-Nr. 2535 / Electrical parts list - diagram No. 2535 /
Liste des pièces électriques - schéma no. 2535
douille 0,75-1,0mm
2
, 25 pcs.
X5 033 04 84 00 PE-Schiene / PE - rail / rail en PE
X10 035 02 03 10 6pol. Gehäuse für Flachsteckhülsen / 6 pole housing for receptacle /
embase à 6 pôles pour alvéole
035 02 00 31 Flachsteckhülse 6,3x1, 5 Stück / receptacle 6,3x1, 5 off /
alvéole 6,3x1, 5 pcs.
1X10 an Pumpe 6pol. Gehäuse für Flachstecker / 6 pole housing for flat plug /
embase à 6 pôles pour fiche plate
an Pumpe Flachstecker 6,3x1, 6 Stück / flat plug 6,3x1, 6 off /
fiche plate 6,3x1, 6 pcs.
X11 035 02 03 10 6pol. Gehäuse für Flachsteckhülsen / 6 pole housing for receptacle /
embase à 6 pôles pour alvéole
035 02 00 31 Flachsteckhülse 6,3x1, 5 Stück / receptacle 6,3x1, 5 off /
alvéole 6,3x1, 5 pcs.
1X11 am Lüfter 6pol. Gehäuse für Flachstecker / 6 pole housing for flat plug /
embase à 6 pôles pour fiche plate
am Lüfter Flachstecker 6,3x1, 6 Stück / flat plug 6,3x1, 6 off /
fiche plate 6,3x1, 6 pcs.
X12 035 02 00 91 4pol. Gehäuse für Flachsteckhülsen / 4 pole housing for receptacle /
embase à 4 pôles pour alvéole
035 02 00 31 Flachsteckhülse 6,3x1, 4 Stück / receptacle 6,3x1, 5 off /
alvéole 6,3x1, 5 pcs.
1X12 035 02 00 42 4pol. Gehäuse für Flachstecker, an Haupttrafo /
4 pole housing for flat plug, at main transformer /
embase à 4 pôles pour fiche plate, sur transformateur principal
035 02 00 41 Flachstecker 6,3x1, 4 Stück / flat plug 6,3x1, 4 off /
fiche plate 6,3x1, 4 pcs.
X13 035 02 00 22 Flachsteckhülse 6,3mm, isoliert 2 Stück / receptacle 6,3 mm, insulated, 2 off/
alvéole 6,3 mm, isolé, 2 pcs.
1X13 an F9 Flachstecker, an Thermoschalter Gleichrichter /
flat plug, at thermal switch, rectifier /
fiche plate, sur commutateur thermique, redresseur
X14 035 02 03 27 8pol. Gehäuse für Flachstecker / 8 pole housing for flat plug /
embase à 8 pôles pour fiche plate
035 02 00 41 Flachstecker 6,3x1, 8 Stück / flat plug 6,3x1, 8 off /
fiche plate 6,3x1, 8 pcs.
1X14 035 02 03 28 8pol. Gehäuse für Flachsteckhülsen, an Kaskade /
8 pole housing for receptacle, at cascade /
embase à 8 pôles pour alvéole, sur cascade
035 02 00 31 Flachsteckhülse 6,3x1, 8 Stück / receptacle 6,3x1, 8 off /
alvéole 6,3x1, 8 pcs.
X20 011 03 67 09 10pol. Buchsengehäuse 3,96, Trafo-Steuerung / 10 pole bushing housing
3,96, transformer control / embase à douille à 10 pôles 3,96, commande
transformateur
011 03 67 02 Crimpbuchse 0,2-0,8mm², verzinnt 10 Stück /
crimp bush 0,2-0,8mm², tinned, 10 off /
