21
2.2.4 Additional parameters of operating mode "Super-4-cycles"
In addition to the secondary parameters for the operating modes, "2-cycle"
and "4-cycle", the following secondary parameters are available:
• Start program (time) Correction value (Off, +/-99, torch)
• Step Modulation Correction value (+/- 9,9 m/min)
• Number of steps (0,1 … 10)
• End crater program (time) Correction value (Off, +/-99, torch)
• Release the start and end crater program with the torch button:
To release the start and end crater program with the torch button,
change the correction value to "Torch" in the Super 4-cycle operating
mode.
• Release power continuation with the torch button:
The power continuation is defined by the "Step modulation" and
"Number of steps" parameters in the secondary parameters menu.
• "Step modulation":
increases or decreases the power by the correction value each time
the button is pressed.
• "Number of steps":
determines the number of times the button can be pressed for
the increase or reduction. When the maximum number of steps is
reached, the power is changed in the opposite direction each time
the button is pressed.
2.2.5 Additional parameters of operating mode "Spot Welding/In-
terval"
In addition to the secondary parameters for the operating modes, "2-cycle"
and "4-cycle", the following secondary parameters are available:
• Spot welding time absolute value (0 … 99,9 s)
• Pause time absolute value (0 … 99,9 s )
