Cloos qineo PULSE MASTER-Plus - Sense Technology; QWD Pushpull

35
3.7 Sense technology
This function is only effective in the Control Weld (MAG normal) operating
mode.
The sense technology supervises the differential voltage between the torch
and the terminal voltage on the welding power source. The Sense lines
have an immediate effect on the regulator settings of the welding process.
If a defined differential voltage is exceeded, there is - for safety reasons - an
immediate switching on the terminal voltage of the welding power source.
Function Description
Sense technology On/Off Switch mode On or Off
Sense technology Differential volt-
age
The differential voltage can be set
between 0.0 V and 40.0 V.
If the adjusted differential voltage
is exceeded, the error message 25
will be displayed: "Sense voltage
exceeded!"
3.8 QWD PushPull
Which PushPull drive should be connected to which wire drive
(QWD1 … QWD4) is configured here.
• No drive
• Cloos Arcette
• Cloos Arcette 2
• Binzel PP+401D
• TBI PPP 7G/7W
• Dinse DIX MPZ 304
• Not defined
Blocked drives will be displayed in red in the selection. These drives may be
activated optionally.
NOTICE!
