IntroductoryDisplay
IQDISPLAYMODULE(IQDM)ANDIQDM-P
DIAGNOSTICS:EXCELSYSTEM
INTRODUCTORYDISPLAY
Immediatelyafterthehandsetisconnectedtothevehicle,itbeginsloadingthevehiclespeedcontrollerinformation.
Afterafewseconds,thescreendisplaysthefollowingmenuitems:
•Program(IQDM-Ponly)
•Monitor
•Faults
•Functions
•Information
•ProgrammerSetup
Intheeventthatthehandsetdoesnotdisplayanyinformation,orthescreenisdifculttoread,refertotheIQDM
troubleshootingprocedures.SeeIQDMandIQDM-PHandsetTroubleshootingonpage14-18.
MENUNAVIGATION
TheNAVIGATIONBUTTON(1)isthefour-arrowbuttonlocatedontheleftsideofthehandset(Figure14-3,Page
14-3).Thisbuttonisusedtonavigatethroughandselectmenus.Pressingtheupordownarrowsallowstheuserto
scrollthroughthemenuitems.Whentheboxbesidethedesiredmenuisblinking,pressingtherightarrowselectsthat
menuitem.Pressingtheleftarrowallowstheusertogobackonescreen(2).
TheCHANGEVALUEBUTTON(3)isthebuttonlocatedontherightsideofthehandset(Figure14-3,Page14-3).
Thisbuttonallowstheusertochangevaluesbypressing+or–.
Thethreeyellowbuttonslabeled1,2and3areBOOKMARKBUTTONS(4)(Figure14-3,Page14-3).Thesebuttons
allowtheusertobookmarkuptothreespecicscreensforrapidreturntothosescreens.Tobookmarkaspecic
displayscreen,havethedesiredscreendisplayedandsimplypressandholdabookmarkbuttonuntilthestatement
“bookmarkset”isdisplayed.Whenitisnecessarytogobacktothebookmarkedscreen,rapidlypressandreleasethe
appropriatebookmarkbutton.SeefollowingNOTE.
NOTE:Whengoingtoabookmarkeddisplayscreen,besuretorapidlypressandreleasethebutton.Ifthebuttonis
pressedandheldfortoolong,thebookmarkwillbeoverriddenwiththecurrentscreen.
