IQDISPLAYMODULE(IQDM)ANDIQDM-P
DIAGNOSTICS:EXCELSYSTEMMonitorMenu
14
SPEED
Vehiclespeedinmph.OnlyvisiblewiththeIQDM-P
THROTTLE
Indicatesthepositionoftheacceleratorpedalfrom0%(pedalnotpressed)to95-100%(pedalfullypressed).This
itemcanbemonitoredwhenthekeyswitchisintheONorOFFposition.
BATTAUXVOLTAGE
Displaysthecurrentbatteryvoltageatthespeedcontroller.
TEMPERATURE
Displaysthetemperature(indegreesCelsius)ofthespeedcontrollerheatsink.Duringnormaloperatingconditions,the
heatsinktemperatureshouldbebelow85°C±5°C(185°F±9°F).SeefollowingNOTE.
NOTE:Improperbrakeadjustmentcansometimescausetheoperatingcurrenttobehigherthannormal.Thishigher
currentincreasesthetemperatureofthespeedcontrollerheatsink.
ARMCURRENT
Displaysthemotorarmaturecurrent(inamperes).
FIELDCURRENT
Displaysthemotoreldcurrent(inamperes).
ARMATUREPWM
DisplaysmotorarmaturePWM(pulsewidthmodulation).Therangeofpulsewidthmodulationis0%to100%.When
thevehicleisoperatingatfullspeed,thepulsewidthmodulationshouldbeat100%.
FIELDPWM
DisplaysmotoreldPWM(pulsewidthmodulation).Therangeofpulsewidthmodulationis0%to100%.Whenthe
vehicleisinoperation,thepulsewidthmodulationwilluctuateinresponsetotheterrainandthrottleinput.
2009ElectricPrecedentMaintenanceandServiceManualPage14-5

Club Car 2009 Electric Precedent Specifications

General

Year	2009
Model	Precedent
Power Source	Electric
Type	Golf Car
Seating Capacity	2
Motor	48V DC
Battery Type	Six 8-volt
Charger	48V Onboard
Top Speed	19 mph
Overall Length	91.5 in (232 cm)
Load Capacity	800 lbs
Frame	Aluminum
Tires	18 x 8.5-8
Overall Width	47 in (119 cm)
Turning Radius	10 ft (3 m)
Curb Weight (without batteries)	637 lb (289 kg)
Weight (without batteries)	637 lb (289 kg)
