Club Car 2009 Electric Precedent User Manual

16
BatteryChargerBATTERIES
CHARGINGBATTERIES
WARNING
•Besureallwireconnectionsatthereceptacleandthefuselinkarecleanandtight.
•Donotrockorbendtheplug.Toconnectthechargerplugtothevehiclereceptacle,grasptheplug
handleandpushtheplugstraightintothereceptacle(Figure16-9,Page16-21).
•DonotpullontheDCcord(Figure16-10,Page16-21).Donottwist,rockorbendtheplug.To
disconnectthechargerplugfromthevehiclereceptacle,grasptheplugbythehandleandpullthe
plugstraightoutofthereceptacle.
•Donotconnectachargertothereceptacleifthechargercord,plug,orthevehiclereceptacleis
broken,damagedinanymanner,ordoesnotmakeagoodelectricalconnection.Fireorpersonal
injurycanresult.Haveitreplacedbyaqualiedservicepersonimmediately.
•Failuretofollowtheseinstructionscouldresultindamagetothechargercord,theplug,and(or)
thevehiclereceptacle.
•Donotuseachargerif:
–Theplugistoolooseordoesnotmakeagoodconnection.
–Theplugandreceptaclefeelhotterthannormalduringcharge.
–Theplugpinsorreceptaclecontactsarebentorcorroded.
–Theplug,receptacle,orcordsarecut,worn,haveanyexposedwiresoraredamagedinanyway.
•Usingthechargerwithanyoftheabovesymptomscouldresultinare,propertydamage,personal
injury,ordeath.
NOTE:Whentemperaturesfallbelow18.3°C(65°F),batterieschargedinunheatedareasshouldbeplacedon
chargeassoonaspossibleafteruse.Batteriesarewarmestimmediatelyafteruse,andcoldbatteries
requiremoretimetofullycharge.
InsertthechargerDCplugintothevehiclereceptacle.Thechargerwillturnontwototensecondslater(Figure
16-9,Page16-21).
WheninsertingtheDCplug,aligntheraisedguideontheplugwiththeguideslotinthereceptacleandpush
straightinslowly.
ClubCarbatterychargersinteractwiththevehicle’sonboardcomputer.Thecomputerrecordstheamountofenergy
consumedduringvehicleuse.Whilethechargerispluggedin,thevehicle’scontrolcircuitislockedout,preventing
operationofthevehicleaswellasthepossibilityofconsequentdamagetothechargerandthevehicle.
Oncethelockoutisactuated,thechargerturnson.Theonboardcomputerthenrecordstheamountofenergybeing
returnedtothebatteries.Whentheoptimumamountofenergyneededtoreplenishthebatteriesisreturned,the
chargerwillshutoff.Thecontrolcircuitlockoutremainsactivateduntilthechargerplugisdisconnectedfromthevehicle.
Page16-202009ElectricPrecedentMaintenanceandServiceManual

Club Car 2009 Electric Precedent Specifications

General

Year	2009
Model	Precedent
Power Source	Electric
Type	Golf Car
Seating Capacity	2
Motor	48V DC
Battery Type	Six 8-volt
Charger	48V Onboard
Top Speed	19 mph
Overall Length	91.5 in (232 cm)
Load Capacity	800 lbs
Frame	Aluminum
Tires	18 x 8.5-8
Overall Width	47 in (119 cm)
Turning Radius	10 ft (3 m)
Curb Weight (without batteries)	637 lb (289 kg)
Weight (without batteries)	637 lb (289 kg)
