BODYANDTRIMRearBody–Two-PassengerVehicles
4
REARBODY–TWO-PASSENGERVEHICLES
SeeGeneralWarningsonpage1-1.
UNIVERSALACCESSORYMOUNTING
TheStructuralAccessoryModule(SAM)includestwothreadedinsertsonboththedriversideandthepassengerside
(Figure4-6,Page4-9).Theseinsertsserveascommonattachmentpoints(1)forvariousaccessories.Accessories
thatcanbemountedtotheSAMincludesingleordualsandbottles,sandbucket,andtheclubcleaner.
1
621
Figure4-6UniversalAccessoryMounting
BACKRESTANDSTRUCTURALACCESSORYMODULE(SAM)
SAMRemoval
1.Ifthevehiclehasacanopy,therearuprightsupportsmustberemovedfromtheSAM.
2.Removefourbolts(4)toreleasetheSAM(3)fromthevehicle(Figure4-7,Page4-10).
SAMInstallation
PositiontheSAM(3)overitsmountingholesandsecurewithfourscrews(4).Tightenscrewsto53in-lb(6N·m).
Backrest
Thebackrest(1)issecuredtotheSAM(3)withtwoscrews(2)(Figure4-7,Page4-10).Whenreplacingthebackrest,
tightenscrews(2)to5.9ft-lb(8N·m).
BagRackRemoval
1.Removetwoscrews(10)toreleasethebaghoop(6)andrelatedcomponentsfromtheSAM(3)(Figure4-7,
Page4-10).
2.Bagstrap(8)maybereleasedbyremovingtwoplasticbarrelconnectors(9)andonescrew(12).
3.Bagstrapbuckles(7)maybesnappedoutofbaghoop(6).
BagRackInstallation
Installationisthereverseofremoval.Tightenscrew(12)to4.8ft-lb(6.5N·m)andscrews(10)to11.8ft-lb(16N·m).
SweaterBasket
Thesweaterbasket(11)issecuredtothebaghoopassemblybythreescrews(12).T absontheupperedgeofthe
basketalignwithholesinthebaghoop(6)forinstallationpurposes.Tightenscrews(12)to4.8ft-lb(6.5N·m)to
securethesweaterbasket(Figure4-7,Page4-10).
2009ElectricPrecedentMaintenanceandServiceManualPage4-9

Club Car 2009 Electric Precedent Specifications

General

Year	2009
Model	Precedent
Power Source	Electric
Type	Golf Car
Seating Capacity	2
Motor	48V DC
Battery Type	Six 8-volt
Charger	48V Onboard
Top Speed	19 mph
Overall Length	91.5 in (232 cm)
Load Capacity	800 lbs
Frame	Aluminum
Tires	18 x 8.5-8
Overall Width	47 in (119 cm)
Turning Radius	10 ft (3 m)
Curb Weight (without batteries)	637 lb (289 kg)
Weight (without batteries)	637 lb (289 kg)
