Club Car 2009 Electric Precedent User Manual

7
FrontSuspensionComponentsSTEERINGANDFRONTSUSPENSION
2.Installthekingpin(7)overtheleafspringeye.Insertthebolt(8)(Figure7-19,Page7-16).Tightentheboltto
30ft-lb(41N·m).
3.Installthewavewasher(6)onthekingpin.
4.Installthesteeringspindleonthekingpin.Placeupperclevisoverthekingpinthreadsandinstallnut(1).Tighten
thenutto70ft-lb(95N·m).
5.Attachthetierodends(12)tothespindletabs,theninstallandtightenthenuts(14)to70ft-lb(95N·m)(Figure
7-18,Page7-15).
6.Installfronthubandwheel.SeeHubInstallationonpage7-17.
CONTROLARMREMOVAL
1.Disconnectthebatterycablesanddischargethecontrollerasinstructed.SeeWARNINGS“Toavoid
unintentionallystarting...”and“Afterdisconnectingthebatteries,wait90seconds...”inGeneral
Warningsonpage1-1.
2.Loosenlugnutsonbothfrontwheelsandraisefrontofthevehiclewithachainhoistoroorjack.Placejack
standsunderthefrontaluminumrailsofthevehicleframeandlowerthevehicleontothejackstands.
3.Removewheel.
4.Removebolts(17)andmoverackandpiniontoallowclearanceforbolt(19)(Figure7-18,Page7-15).
5.Removebolts(11and19).
6.Removethecontrolarm(6).
7.Inspectthebushings(7)andsleeves(8and9)inthecontrolarmandreplacethemifnecessary.
CONTROLARMINSTALLATION
1.Installthecontrolarminreverseorderofremoval.Tightenthecontrolarmbolts(11and19)to30ft-lb(41N·m)
(Figure7-18,Page7-15).Tightenthreerackandpinionmountingbolts(17)to22ft-lb(30N·m)
2.Installthewheelsandadjustthewheelalignmentasinstructedonpage7-10.
SHOCKABSORBERREMOVAL
1.Inspecttheshockabsorbersforuidleakageatthepointwheretheshaftenterstheshockabsorberbody.
Leakingshockabsorbersshouldbereplaced.
2.Removetheupperbolt(18)(Figure7-18,Page7-15).
3.Removethelowerbolt(10).
4.Removetheshockabsorber.
SHOCKABSORBERINSTALLATION
NOTE:Wheninstallingshockabsorbers,makesurefrontshockshaveidenticalpartnumbers.
1.Installtheshockabsorberbyreversingtheremovalprocedure.
2.Tightentheboltsto16ft-lb(21N·m).
Page7-142009ElectricPrecedentMaintenanceandServiceManual

Club Car 2009 Electric Precedent Specifications

General

Year	2009
Model	Precedent
Power Source	Electric
Type	Golf Car
Seating Capacity	2
Motor	48V DC
Battery Type	Six 8-volt
Charger	48V Onboard
Top Speed	19 mph
Overall Length	91.5 in (232 cm)
Load Capacity	800 lbs
Frame	Aluminum
Tires	18 x 8.5-8
Overall Width	47 in (119 cm)
Turning Radius	10 ft (3 m)
Curb Weight (without batteries)	637 lb (289 kg)
Weight (without batteries)	637 lb (289 kg)
