MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 10 of 127
Max. longitudinal
stabilization
5,20 m
17.06 ft
Max. cross stabilization
3,84 m
12.60 ft
Min. longitudinal
stabilization
3,81 m
12.50 ft
Min. cross stabilization
2,46 m
8.07 ft
Intermediate cross
stabilization
3,15 m
10.33 ft
Outriggers plate Ø
0,18 m
0.59 ft
WEIGHT AND PRESSURES
Total weight
(standard)
2865 kg
6317 lb
(R) Max. pressure on
the foot
8,4 kg/cm²
(82,38 N/cm²)
119.48 lb/in
2
(S) Max. pressure on
tracks
0,2 kg/cm²
(2,03 N/cm²)
2.84 lb/in
2
(T) Max. pressure in
travel
651 kg/m²
(6,38 KN/m²)
133.34 lb/ft
2
(U) Max. pressure in
work (wide area)
225 kg/m²
(2,21 KN/m²)
46.08 lb/ft
2
(V) Max. pressure in
work (narrow area)
224 kg/m²
(2,20 KN/m²)
45.88 lb/ft
2
(Y) Max. pressure in
work (mixed area)
258 kg/m²
(2,53 KN/m²)
52.84 lb/ft
2
POWERS
Standard
hydraulic feed
1) Honda iGX390 petrol, 8.7 kW
(11.7 HP), 3600 rpm
*Optional feeds
2) Yanmar L100W diesel, 6.8 kW
(9.1 HP), 3600 rpm
3) Kubota Z602-E4B diesel, 10.8
kW (14.5 HP), 3200 rpm
4) Electric motor: 230/120/110 V
5) Motor G0901306, 9 kW, 48 V,
with lithium batteries 160 Ah
Fuel tank capacity
6,1/15 l
Max values (speed/force) allowed
according to USA/EU standards
Max. lifting and descending
speed of the MEWP
0,4 m/s (1.31 ft/s)
Max. boom extension and retrac-
tion speed
0,4 m/s (1.31 ft/s)
Max. rotation speed
0,7 m/s (2.3 ft/s)
Max. manual force in the basket
with 1 operator
400 N
Tightening
torque
Slewing ring bolts
M16 cl 10.9
28 daNm
