MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 82 of 127
6 Electrical system
The MEWP is electrically supplied when the key is
inserted and rotated in position 1 (Picture 4).
Periodically check the efficiency of the electrical sys-
tem: battery, alternator, regulator alternator charge.
The electrical system is attached to this manual.
Any operation requiring interventions on
the components of the machine, shall car-
ried out by authorized and trained staff.
It is forbidden to replace the components for
non-authorized staff. Many components of
the MEWP have been calibrated: a correct
calibration of these parts (which is possi-
ble only in CMC or in authorized Services)
is important to assure the safety of the ma-
chine.
• FUSE BOX (Picture 87):
At view on machine switching on/off station, there
is a fuse box where it is possible to find all the
machine fuses. You can also identify the burnt
ones through the lighting of a related led.
Picture 87: fuse box.
