CMC S23 - Specifications; Technical Sheet

MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 9 of 127
2 Specifications 
2.1 Technical sheet 
PERFORMANCE
Max. working height
23,00 m
75.46 ft
Max. work outreach
(with 200 kg)
12,40 m
40.68 ft
Max. load on the basket
200 kg
441 lb
Turret rotation
+/-355° (tot. 710°)
Basket rotation
(*optional)
+/-90°
Work angle of Jib
90°
Max. slope to stabilize
13° / 23%
Max. slope approach an-
gle (engine side/basket
side without jib)
14°-15° / 25-27%
Max. slope to travel (lon-
gitudinally/transversally)
17°-10° / 31%-18%
Travel speed
0,60-1,40
km/h
0.37-0.88
mph
DIMENSIONS
Basket height
1,10 m
3.61 ft
Basket width
0,60/0,70
m
1.97/2.30
ft
Basket length
0,80/1,40
m
2.62/4.59
ft
Total length with basket
5,50 m
18.05 ft
Length with
basket support rotated
5,10 m
16.73 ft
Height in transport position
1,98 m
6.50 ft
Total width (without basket)
0,88 m
2.89 ft
Clearance from the ground
under chassis in transport po-
sition
0,20 m
0.66 ft
Max. height to stabilize on an
obstacle (with tracks lifted)
0,75 m
2.46 ft
Tracks (L x w)
1,75 x
0,25 m
5.74 x
0.82 ft
Tracks widening (*optional)
0,85/1,25
m
2.79/4.10
ft
