4.4.7 "Home" function
The following procedure should be car-
ried out with the most caution and wearing
all personal protective equipment.
This function is very useful at the end of works to set
the platform in transport configuration.
When the appropriate button (dead man) "Home" 12
(Picture 8), present on the radio control station, is
held pressed, the automatic closing of the aerial part
is activated.
The following maneuvers must be carried out up to
the limit switches in order:
o boom return up to 0°;
o turret rotation in the original direction up to 0°;
o pantograph descent up to 0°;
o boom lowering up to the support.
CAUTION! IF YOU MEET OBSTACLES
DURING THE AUTOMATIC CLOSURE OF
THE MACHINE, IMMEDIATELY RELEASE
THE BUTTON AND PROCEED WITH THE
MANUAL MANOEUVRES.
4.4.8 Acoustic warnings
During the use of the MEWP, it is possible to hear the
following acoustic warnings (*optional), correspond-
ing to the following signals:
 SOUND 
Corresponding to:
Continuous acoustic
signal (intermittent in
pre-alarm): when ex-
ceeding the maxi-
mum travel inclina-
tion allowed.
Maximum travel inclina-
tion light activated on
basket control station and
on wired remote control.
Table 3: acoustic signals.
4.5 Lithium battery pack re-
charge (*optional)
For full lithium version (*optional), in order to
recharge the battery pack, it will be necessary to stall
the machine.
Then operate according to the following procedure:
1. switch off the electric engine;
