MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 74 of 127
Picture 37: AUTEC wired remote control station.
Picture 38: AUTEC electronic panel of
radio/wired control station.
Picture 39: display box.
Picture 40: dual power selector (*optional).
Picture 41: safety belt attachment point.
Picture 42: indication of air/water supplies.
Picture 43: indication of 12 V socket.
