8.11 Maintenance of endothermic
engine
The standard supplied motor has the following tech-
nical characteristics:
o HONDA iGX390 petrol engine, single cylinder
OHV with horizontal shaft, 4 strokes, cylinder
inclined at 25°, forced air cooling, cast iron
cylinders.
Data
Value
Unit of
measure
Bore x Stroke
Ø 88 x 64
mm
Cylinder capacity
389
cm
3
Net power at 3600
rpm
8.7 (11.7)
kW (HP)
Maximum torque
at 2500 rpm
26.5
N/m
Dry weight
81.57
lbs
Dimensions (L x W
x H)
1332 x 1509
x 1470
ft
Fuel consumption
at 3600 rpm
3.5
l/h
Fuel tank capacity
6.1
l
Other engines, provided as optional*, has the follow-
ing technical characteristics:
o YANMAR L100, diesel engine, air-cooled,
vertical cylinders, 4 stroke.
Data
Value
Unit of
measure
Bore x Stroke
Ø 86 x 75
mm
Displacement
0.435
l
Continuous rated
power (3000 -
3600 rpm)
5.7 - 6.2
kW
Maximum rated
power
(3000 - 3600 rpm)
6.3 - 6.8
kW
Dry weight
53.5
kg
Dimensions (L x W
x H)
412 x 472 x
494
mm
Fuel tank capacity
5.4
l
o Kubota Z602-E4B, 4-cycle diesel engine, wa-
ter cooled, naturally aspirated, indirect injec-
tion, 2 vertical cylinders.
Data
Value
Unit of
measure
Bore x Stroke
Ø 72 x 73.6
mm
