Note: Combine and Serial Ports are not used with system operation.
WIP Integrated Dry Pair Tester (DPT)
Refer to “WIM 8 (RD) Integrated Dry Pair Tester (DPT)” on page 24.
WIP Screens
Refer to “WIM 8 (RD) Screens” on page 24.
Flexible Combine Module (FCM)
Refer to “Flexible Combine Module (FCM)” on page 25.
Ringdown Circuits
Refer to “Ringdown Circuits” on page 25.
A. LCD
B. Flexible Combine Modules — FCM (2)
C. Monitor Port
D. User “soft buttons,” function indicated on LCD
E. Ringdown instrument connections
F. Dual Assignment Thumbwheels (1 through 10)
G. Wired back up ports, 6 pin XLR, two line (1
through 10)
H. Dry pair connections, RJ-14s
I. Connections to WAM 10
J. Connections to local PS 4001 power supply(s)
K. Test Enable Switch
L. Dry pair connections, Spring Jacks
M. Interconnect to PS-4001 power supplies,
Ethercon
