Lists of events
98-145510-E Appendix E: System messages E-6
E.2.2 Antenna events
Event ID Severity Description Explanation
0A001-0 ERROR Production data Production data is invalid.
0A002-0 ERROR XIM internal Antenna configuration data stored in the PCM module is
invalid.
0A003-0 ERROR XIM external Antenna configuration data stored in the VIM/TIM
module is invalid.
0A004-0 ERROR XIM I/X match Antenna configuration data stored in the PCM module
does not match the configuration data stored in the
VIM/TIM module.
0A005-0 ERROR Antenna type The configured antenna type is not supported or
unknown.
0A006-0 ERROR PCM FPGA load The PCM FPGA cannot be initialised and loaded
correctly.
0A007-0 ERROR XIM FPGA load The VIM/TIM FPGA cannot be initialised and loaded
correctly.
0A008-0 ERROR XIM production Production/calibration data stored in the VIM/TIM
module is invalid.
0A00A-0 ERROR GNSS initialisation The GNSS device cannot be initialised. Check cable and
GNSS device.
0A014-0 ERROR AMB device discovery Missing one or more of the following devices: ISM, DDM
and PMM. Check cables.
0A015-0 ERROR Azi DDM ABS device Cannot initialise the azimuth DDM. Info: 0x00000000:
Device not found (possible cabling problem)
0x0000bbaa: Device internal error (replace device)
aa=status, bb=state.
0A016-0 ERROR Xel DDM ABS device Cannot initialise the cross-elevation DDM. Info: See
0A015-0.
0A017-0 ERROR Ele DDM ABS device Cannot initialise the elevation DDM. Info: See 0A015-0.
0A018-0 ERROR ISM ABS device Cannot initialise the ISM Info: 0x00000000: Device not
found (possible cabling problem) 0x000cbbaa:
Device internal error (replace device) aa=status,
bb=state, c=calibration data error.
0A019-0 ERROR PMM ABS device Cannot initialise the PMM. Info: See 0A015-0.
0A01A-0 ERROR BCM ABS device Cannot initialise the BCM. Info: See 0A015-0.
Table E-2: Event messages for antenna
