98-145510-E Appendix E: System messages E-7
0A01E-0 ERROR Sensor sanity Too many invalid values measured by the ISM during
initialisation. Check for vibrations or malfunctioning ISM.
0A021-0 ERROR Azi axis calibration Azimuth axis zero reference not found. Check belt and
zero reference module. Info: 0x00000001: Timeout
(operation did not complete in time) 0x00000010:
Encoder or mechanical problem 0x00000020: Zero
reference not found 0x00000040: End stop not
found.
0A022-0 ERROR Xel axis calibration Cross-elevation axis zero reference or end stops not
found at expected locations. Check belt, zero reference
module, and end stops. Info: See 0A021-0.
0A023-0 ERROR Ele axis calibration Elevation axis zero reference or end stops not found at
expected locations. Check belt, zero reference module,
and end stops. Info: See 0A021-0.
0A024-0 ERROR Pol axis calibration Polarisation axis zero reference or end stops not found at
expected locations. Check movement of the polarisation
unit and the zero reference module. Info: See 0A021-0.
0A025-0 ERROR Antenna calibration One or more errors occurred during antenna start-up
Info: 0x00000001: Timeout (calibration did not
complete in time) 0x00000010: Azimuth axis
0x00000020: Cross-elevation axis 0x00000040:
Elevation axis 0x00000080: Polarisation axis
0A028-0 ERROR Demodulator load The second receiver demodulator cannot be initialised
and loaded correctly.
0A029-0 ERROR XIM PLL lock The PLL on the VIM/TIM does not lock.
0A02B-0 ERROR ABS software version The ABS software version in the antenna is too old to
match the hardware requirements. Upload new software
via the web interface.
0A034-0 WARNING ACU communication The communication link between ACU and antenna is
not working.
0A035-0 WARNING ISM data valid Sensor measurements from the ISM are invalid. This
indicates a malfunctioning ISM.
0A036-0 WARNING ISM data range Sensor measurements from the ISM are out of range.
0A037-0 WARNING GNSS communication Lost connection to the GNSS device.
0A038-0 WARNING GNSS data range Received information from the GNSS device which is out
of range.
Event ID Severity Description Explanation
Table E-2: Event messages for antenna (Continued)
