The web interface
98-145510-E Chapter 6: Setup and operation 6-4
Examples of system status:
• Antenna SW upload
• Antenna POST (Power-On Self Test)
• Ready (waiting for data from the modem or no satellite profile selected)
• Tracking (antenna is locked to the satellite signal and ready to send/receive.
• Not ready: Not deployed (the system is waiting for the user to deploy the antenna)
• Safe mode (error, followed by an error description)
Information fields on the Dashboard
The information on the Dashboard varies depending on the antenna and the used
satellite and modem profiles.
DASHBOARD Description
GNSS position Current position, reported by the GNSS module or entered
manually
Base orientation Orientation of the mounting base relative to estimated North
Satellite profile Name of the currently active satellite profile
Satellite position Position of the satellite selected in Satellite profile
RX polarization Horizontal, Vertical, (Left-hand or Right-hand)
TX polarization Horizontal, Vertical, (Left-hand or Right-hand)
RX RF frequency Receiving frequency
LNB LO frequency The LNB Local Oscillator frequency
TX RF frequency Transmitting frequency
BUC LO frequency The BUC Local Oscillator frequency
Tracking RF frequency Current RF tracking frequency
ACU part name, Antenna
part name, ACU serial
number, Antenna serial
number, Software
version
Part names, serial numbers for ACU and antenna, software
version of the VSAT system
POINTING Description
Azimuth, elevation geo Current value for geographic azimuth and elevation
Azimuth, elevation rel Current value for relative azimuth and elevation
Polarization skew Current value for polarization skew
Table 6-3: DASHBOARD information fields
