The web interface
98-145510-E Chapter 6: Setup and operation 6-5
MODEM Description
Model VSAT modem name, entered in SETTINGS > Modem profiles.
RX locked status Shows whether or not the system has locked to the incoming
signal.
Signal level Current input signal level from VSAT modem.
iDirect openAMIP modem: (PWR) 0-500, delivered by the
connected modem. For values <250 the antenna searches after a
new signal.
Other modem: Signal level in dB.
RX IF frequency RX IF frequency read from the VSAT modem
TX IF frequency TX IF frequency read from the VSAT modem
TX allowed On or Off. Indicates if the VSAT modem supplies the 10 MHz
reference signal on its TX connector (On) and if an iDirect
OpenAMIP modem indicates modem Locked and Tx ON in the
OpenAMIP message L (L 1 1).
TX mute Muted or Not muted. Indicates whether or not the antenna is
muted. You can mute the antenna using the TX mute input on
the User I/O connector. See User I/O on page 4-7.
TX Description
BUC TX On or Off. Shows if the VSAT system has enabled the BUC or not.
It is the same TX ON/TX OFF as shown in the display of the ACU,
see Keypad and display menus on page 6-27.
BUC output power Shows whether or not the BUC is transmitting and the power
level. At the P1dB compression point 4 bars are filled.
EIRP The EIRP readout is only valid for continuous modulated signals
and is for indicative use only (limited accuracy).
Table 6-3: DASHBOARD information fields
