Table 2: Equipment Covered
Table 3: Associated Equipment
Equipment Description Part Number
DAU-7060
OR
DAU-7070
OR
ANY APPROVED DLNA
“Modified Type A” Diplexer / Low Noise Amplifier
“Type F” Diplexer / Low Noise Amplifier
677-A0179
677-A0193
DLNA ANT to RF OUT
CABLE
RF cable assembly for interconnecting the HGA-
7001 and the DLNA
660-A0605-XXX or other
approved cable
(XXX denotes the cable
length in centimetres.
Please contact the
Supplier in this regard.)
Table 4: Related Publications
Equipment Description Part Number
HGA-7001 High Gain Antenna which is ARINC 781 compliant
and conforms to the Inmarsat SDM for an Aero H
Antenna. This antenna is approved for use with
Aero-H/H+, SBB and Swift64 SATCOM systems.
677-A0173
Publication Part Number
ARINC 429 Mark 33 Digital Information Transfer System Parts 1, 2, 3
ARINC Characteristics 741 P1-9 Aviation Satellite Communications System.
ARINC Characteristics 781 Mark 3 Aviation Satellite Communications Systems,
published: November 22, 2006
Repainting HGA-7001 Antenna Application Note OP 121
RTCA DO-160E: Environmental Conditions and Test Procedures for Airborne
Equipment
HGA-7001 Wiring Diagram
HGA-7001 Outline Drawing
DAU-7060 Outline Drawing
DAU-7070 Outline Drawing
677-A0173_WD
677-A0173-00x_ODx
677-A0179_OD
677-A0193_OD
