HGA-7001
Installation Manual
Document: 862-A0089_IM issue 1.6
COMPANY CONFIDENTIAL
Page 12 of 45
2.2 Leading Particulars
Table 5 lists the physical and equipment specifications for the HGA-7001. Environmental specifications
are also included in this table.
Table 5: Equipment Specifications (Sheet 1 of 3)
Characteristic Specification
ARINC CHARACTERISTICS ARINC CHARACTERISTIC 781-1, MARK 3 AVIATION SATELLITE
COMMUNICATION SYSTEMS, Published: November 22, 2006
RTCA DOCUMENTS RTCA/DO-210D, MINIMUM OPERATIONAL PERFORMANCE
STANDARDS FOR GEOSYNCHRONOUS ORBIT AERONAUTICAL
MOBILE SATELLITE SERVICES (AMSS) AVIONICS, April 19, 2000;
Change 1 to RTCA/DO-210D, December 14, 2000;
Change 2 to RTCA/DO-210D, November 28, 2001;
Change 3 to RTCA/DO-210D, September 19, 2006
RTCA/DO160E, Environmental Conditions and Test Procedures for
Airborne Equipment, December 9, 2004
ENVIRONMENTAL CATEGORY
Temperature and altitude DO-160E Category E1
Operating temperature –55 C to +70 C
(–67 °F to +158 F)
Maximum operating altitude 21 000 meters
(70 000 feet)
In flight Loss of Cooling DO-160E Category X
Temperature variation DO-160E Category A
Humidity DO-160E Category B
Shock DO-160E Category E
Vibration DO-160E Category [U(G),R(C,C1),R(E,E1),H(R),S(LMY)]
Explosion proofness DO-160E Category E
Waterproofness DO-160E Category RS
Fluids susceptibility DO-160E Category F
Sand and dust DO-160E Category S
Fungus resistance DO-160E Category F
Salt spray DO-160E Category S
