HGA-7001
Installation Manual
Document: 862-A0089_IM issue 1.6
COMPANY CONFIDENTIAL
Page 16 of 45
Table 8: Connector Pin Assignments
Pin
Number
Signal Description
1 +28 VDC Aircraft DC Power
2 28 VDC Return Aircraft DC Power
3 Antenna BITE A ARINC 429 from antenna
4 Antenna BITE Shield Shield for ARINC 429
5 Antenna BITE B ARINC 429 from antenna
6 Antenna Control A ARINC 429 to antenna
7 Antenna Control Shield Shield for ARINC 429
8 Antenna Control B ARINC 429 to antenna
9 DLNA BITE BITE from DLNA
10 DLNA Shield Shield/ RTN for DLNA
11 DLNA CTL DLNA on/off control from antenna
12 Serial Shield Serial Shield/GND
13 NC
14 NC
15 NC
16 NC
17 NC
18 115 VAC HOT Aircraft AC Power
19 115 VAC COLD Aircraft AC Power
20 NC
21 NC
22 Chassis Ground Chassis Ground
To Next Page
