COBHAM RT-7000 RCDU - 8.4 INSTALLATION CHECKOUT DATA TABLES AND CHECKLIST

150-071724 Rev N
This document contains proprietary information,
see proprietary statement on first page.
Page 103 of 138
8.4 INSTALLATION CHECKOUT DATA TABLES AND CHECKLIST
Date: _________________
Operator: ______________
Installation Number:
___________
RT-7000 PMR/RMR Part Number:
_________________
(31300-1X02-XXXX)
Transceiver #1 Type
(Wideband, APX,SAR,ect)
________________________________
Transceiver #2 Type
(Wideband, APX,SAR,ect)
________________________________
Transceiver #23 Type
(Wideband, APX,SAR,ect)
________________________________
Step 1
Antenna Conductance Test
RT #1 Antenna Resistance (mohms)
___________
RT #2 Antenna Resistance (mohms)
___________
RT #3 Antenna Resistance (mohms)
___________
Step 2
System Power-Up Test
RT-7000 PMR Powered On (yes/no)
___________
Step 3
Display
Display Backlight OK (yes/no)
___________
Step 4
RT-7000 PMR/RMR System Configuration
Verification
RT-7000 PMR/RMR System Configured (yes/no)
___________
Step 5
RT-7000 PMR/RMR Transceiver Information
Program Verification
RT-7000 PMR/RMR – Transceiver 1 programed
(NA, yes/no) ___________
RT-7000 PMR/RMR – Transceiver 2 programed
(NA, yes/no) ___________
RT-7000 PMR/RMR – Transceiver 3 programed
(NA, yes/no) ___________
Step 6
RT-7000 RCDU (remote if applicable) Preset
Channels Program Verification
