COBHAM RT-7000 RCDU - Table 7-8: Antenna Tuner J1 Signals

150-071724 Rev N
This document contains proprietary information,
see proprietary statement on first page.
Page 94 of 138
PI
N
SIGNAL NAME
Connection
Wire
Destination
A
Rx Data +
24 TSP
Antenna Port 1 RT-7000 PMR J101-39
Antenna Port 2 RT-7000 PMR J101-56
Antenna Port 3 RT-7000 PMR J101-39
B
Rx Data -
Antenna Port 1 RT-7000 PMR J101-38
Antenna Port 2 RT-7000 PMR J101-19
Antenna Port 3 RT-7000 PMR J101-20
C
Tx Data +
24 TSP
Antenna Port 1 RT-7000 PMR J101-16
Antenna Port 2 RT-7000 PMR J101-58
Antenna Port 3 RT-7000 PMR J101-18
D
Tx Data -
Antenna Port 1 RT-7000 PMR J101-15
Antenna Port 2 RT-7000 PMR J101-59
Antenna Port 3 RT-7000 PMR J101-17
E
S3 Program
22
Antenna Tuner J1-S
F
Reserved
NC
-
-
G
Reserved
NC
-
H
Reserved
NC
-
J
Reserved
NC
-
K
Reserved
NC
-
L
S0 Program
22
Antenna Tuner J1-M
M
SO Program Ground
22
Antenna Tuner J1-L
N
Reserved
NC
-
P
Reserved
NC
-
Q
Reserved
NC
-
R
Reserved
NC
-
S
S3 Program Ground
22
Antenna Tuner J1-L
T
Reserved
NC
-
V
Reserved
NC
-
Table 7-8: Antenna Tuner J1 Signals
(2) J2
The J2 connector provides power and ground signals to the tuner. J2 is a
KPTO2E-8-33P, 3 pin connector, with aircraft mating connector: KPT06E-8-33S
