CB-MF-SOP-002
A/1
33
12 Replace Fuse of Power Socket
1. Disconnect the power from the device and remove the power cord. Locate the fuse position
at the power outlet below the rear of the device. See the figure below.
Figure 12-1
2. Use tweezers to gently pry open the fuse box and pull it out. See the figure below.
Figure 12-2
3. Remove the fuse with tweezers and other tools. See the figure below.
Figure 12-3
4. Change fuse of specified specification: T6.3AL250V.
5. Reclose the fuse box.
Attention:
To Next Page
