C001537_15_CR2_User_Manual 54
Save Settings
1-Dimensional Codes ONLY (1024 x 200 pixels)
Caution: It may be more diffi cult to read other codes while in this setting. You must have the
reader farther away than normal.
Small 2-Dimensional Codes
(480 x 480 pixels) Medium 2-Dimensional Codes (512 x 512 pixels)
Large 2-Dimensional Codes (640 x 640 pixels) Reset to Default Setting (1024 x 640 pixels)
Users may optimize the CR2 decode zone if their application only requires one bar code format. If the size and density of
the bar codes to be scanned are consistent, please select the setting below that best describes your environment.
5.3 - Mirror Decoding
Scan the following codes to enable/disable the mirroring feature:
On Off (Default)
Note: The Mirroring feature allows the CR2 to read codes as they are seen through a mirror (inversed 180°). If
the Mirroring feature is enabled, non-mirrored reading ability will be disabled.
To Next Page
