DataMan 8700 Imager Specifications
Specifications DataMan 8700 Imager
Image Sensor 1/3 inch CMOS
Image Sensor Properties 3.45 μm square pixels
Image Resolution 1440 x 1080 pixels
DataMan 8700 Base Station Specifications
Base Station Specifications
Specification DMB-8700-USB, DMB-8700-RS, DMB-8700-E DMB-8700-CHARGE
Weight 500 g (17.63 oz) 607 g (21.41 oz)
Operating
Temperature
0 ºC — 40 ºC (32 ºF — 113 ºF)
Storage Temperature -40 ºC — 60 ºC (-40 ºF — 140 ºF)
Maximum Humidity 95% (non-condensing)
Power Supply
Requirements
5.5 V DC, 6 W maximum LPS or NEC Class 2 power supply or PoE
Class 2 power supply
Requirement: 24 V DC,
min 0.5 A
Consumption: Up to 12 W
Protection IP65
Ethernet 10/100 Base-T FULL/HALF DUPLEX, IEEE 802.3 N/A
Bluetooth Bluetooth 4.2, BR/EDR, 2.4~2.4835 GHz N/A
Wi-Fi IEEE 802.11 a/b/g/n/ac, 2.4~2.4835 GHz and 5.18-5.835 GHz N/A
Charge Time N/A < 8 hours
Cable Lengths N/A 2.5 m + 2.5 m, 5 m total
LED Wavelengths for DataMan 8700 Readers
Note: The data below refer to the LED Illumination accessory of the reader, not to the LEDindicators.
The following table shows LED types and the related wavelengths:
Reader Model LED λ [nm]
DM8700 DX RED 660
DM8700 DQ WHITE N/A
DM8700 LX AMBER/RED-ORANGE 617
DM8700 HD AMBER/RED-ORANGE 625
17
