6. Insert the end cap and lock the yellow latch.
Connecting to a Bluetooth DataMan 8700 Through an Intelligent Base Station
1. Open end cap and insert the battery. Make sure you insert the battery into the slot with the metal contact pins pushed
in first.
Tip: A small triangle on one side of the battery is also indicating the correct placement.
32
Connection Options
