5.3 CAT5 Network Cable Specifications
Cognex-supplied, straight-pinned and crossover network patch cables meet CAT5/CAT5e
specifications using 568-B standard wire pairing.
Table 5-5: CAT5/CAT5e Network Cable Wiring
Straight-Pinned
Signal Name RJ-45 Connectors Wire Color
TPO+ 1 White/Orange
TPO- 2 Orange
TPI+ 3 White/Green
TRMA 4 Blue
TRMB 5 White/Blue
TPI- 6 Green
TRMC 7 White/Brown
TRMD 8 Brown
Table 5-6: CAT5/CAT5e Network Cable 568-B Wire Pairs
Pair # Wire Pairs
1 4 — 5
2 1 — 2
3 3 — 6
4 7 — 8
