COMAC Tripla 60B - Front - Side - Rear Components

13
13. Indicator light for signalling the start of the clean water reserve.
14. Button for using the horn.
15. Three-way switch for selecting the working direction.
16. Unipolar switch for selecting the machine movement speed.
11. FRONT - SIDE - REAR COMPONENTS
The rear components are identified as follows:
17. Parking brake pedal
18. Accelerator pedal
19. Water/solution inlet cap
20. Recovery tank fixing hinge
21. Suction cap fixing hinge
22. Dirty water drainage tube
13
14
17
18
19 20
21 22
15
16
