COMAC Tripla 60B - Symbols Used on the Machine

5
SYMBOLS USED ON THE MACHINE
Tap symbol
Indicates the solution quantity adjustment
Tap symbol
Used to indicate water regulation changes (CDS versions)
Detergent symbol
Used to indicate detergent regulation changes (CDS versions)
Battery symbol
Indicates the instructions for dosing the detergent in the canister (CDS version)
Symbol indicating the horn button
Main switch symbol (key switch)
Symbol representing the slow speed selector for machine forwards or backwards movement
Symbol representing the fast speed selector for machine forwards or backwards movement
Symbol denoting suction motor
Used to indicate the suction motor switch
