6
Symbol denoting solution tank empty
Symbol indicating brush release
Symbol denoting the indicator light for brush contactor activation (BS version)
Symbol denoting base rise/fall
Used to indicate the base rise/fall manipulator
Symbol denoting squeegee risel
Used to indicate the squeegee rise/fall manipulator
Symbol denoting the manual/automatic operating mode switch
Symbol denoting forward/backward drive selector
