3. General Guidelines
3.1. Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTION - This manual contains important instructions for IGS-NT
controllers family that shall be followed during installation and maintenance of the Inteli NT
genset controllers.
It is intended for use by Gen-set control panel builders and for everybody who is concerned
with installation, operation and maintenance of the gen-set.
WARNING
Remote control
The controller can be remotely controlled. In the event that maintenance needs to be done
to the gen-set, check the following to ensure that the engine cannot be started.
To be sure:
Disconnect remote control via RS232 or another communication line
Disconnect input REMOTE START/STOP
or
Disconnect output STARTER and outputs GCB CLOSE/OPEN and MCB CLOSE/OPEN.
Be aware the unqualified manipulation can disconnect the object from the power supply
source.
CAUTION!
The controller contains a large number of configurable setpoints, because of this it is
impossible to describe all applications. Controller functions are subject to change from SW
version to SW version. This manual only describes the product and is not guaranteed to be set
for your application on arrival.
!!! CAUTION !!!
Dangerous voltage
The terminals for voltage and current measurement should never be touched.
Properly connect the grounding terminals.
Do not disconnect the Controller CT terminals for any reason.
Adjust set points
All parameters are djusted to their typical values. But the set points in the “Basic settings”
settings group !!must!! be adjusted before the first startup of the gen-set.
!!! WRONG ADJUSTMENT OF BASIC PARAMETERS CAN DESTROY THE GEN-SET !!!
The following instructions are for qualified personnel only.
To avoid personal injury do not perform any action not specified in this User guide !!!
