IGS-NT Installation Guide
13
WARNING – VERY IMPORTANT !!!
Be aware that the binary outputs can change state during and after software
reprogramming. Before the controller is used again ensure that the proper
configuration and setpoint settings are set in the controller.
Every time you want to disconnect following controller terminals:
Mains voltage measuring and / or
Binary output for MCB control and / or
MCB feedback
Be aware that the MCB can be switched off and gen-set can start !!!
Switch controller to MAN mode and disconnect the Binary outputs Starter and Fuel or press
EMERGENCY STOP button to avoid unexpected automatic start of gen-set and GCB closing
during any work or maintenance on the gen-set or switchboard.
3.2. Required and Optional Modules
3.2.1. Inteli New Technology Controllers
Controller
Description
Standard /
Optional
IG-NT
IG-NTC
IM-NT
Controller Central Units with internal display
Standard
IG-NT-BB
IG-NTC-BB
IS-NT-BB
IS-NTC-BB
IM-NT-BB
IM-NTC-BB
Controller Central Unit without internal display
Standard
3.2.2. Accessories
Accessories and
modules
Description
Standard /
Optional
IG-Display
Additional display for IG-NT/NTC/EE/EEC, IM-
NT
Optional
IS-Display
Additional display for IS-NT-BB
Optional
InteliVision 5
Additional colour display for IS-NT-BB, IG-
NT/NTC/EE/EEC, IM-NT, IS-NTC-BB, IG-NT-
BB, IG-NTC-BB
Optional
InteliVision 8
Additional colour display for for IS-NT-BB, IG-
NT/NTC/EE/EEC, IM-NT, IS-NTC-BB, IG-NT-
BB, IG-NTC-BB
Optional
