11
MACHINE PREPARATION
3. CONNECTING THE SYSTEM CONNECTOR
The connector (1) is located in the lower left section (in relation to the operator), and must be
connected to the machine connector (2).
4. MOTOR START-UP (PRE-HEATING)
1. Check the accelerator lever is pressed fully down (1)
2. Turn the key of the main switch to position (2). The green indicator light showing key
insertion (3) will light up, along with the red indicator lights relating to the oil (4) and battery
(5)
3. The yellow indicator light (6) will come on if there is no diesel in the fuel tank.
4. Turn the key to position (7). The yellow indicator light showing glowplug pre-heating (8) will
come on. Wait until the yellow indicator light goes off (after about 10 seconds), then turn the
key again to start up the motor.
