15
MACHINE PREPARATION
10. ASSEMBLING THE CYLINDRICAL BRUSH
This operation must be carried out by a technician from the Comac Technical
Assistance Centre
11. ASSEMBLING THE SIDE BARS
The side bars are already fixed at the front, but they still need to be positioned in
the rear part. Proceed as follows:
1. Insert the rear part of the side bar in the squeegee pin
2. Position the seal clip
3. Repeat the same operations for both side bars
12. HOPPER
Check the hopper is closed and, if necessary, push it until the closing hook is
locked in place (1)
