29
WEEKLY MAINTENANCE
CLEANING THE SUCTION TUBE
Whenever suction seems to be unsatisfactory, check that the suction tube is not
obstructed. If necessary, clean it with a water jet introduced from the side where it
is connected to the tank. Proceed as follows:
1. Loosen the knobs (1) of the vacuum cleaner guard
2. Loosen the tube-holder tie (2)
3. Clean it with a water jet inserted from the side where it enters the tank
4. reassemble everything, carrying out the above-mentioned operations in the
reverse order
CLEANING THE SUCTION MOTOR FILTER
1. Loosen the recovery tank cap
2. Remove the filter retaining clip (3)
3. Take out the filters (4, 5) and clean them thoroughly with a jet of water
4. Replace the double filter (4)
5. Replace the single filter (5), making sure the flanges of the two filters are in
contact
6. reassemble everything, carrying out the above-mentioned operations in the
reverse order
5
3
