18
WORK
1. Carry out the operations to prepare the machine
2. Sit on the driver’s seat
3. Check the parking brake is released (1)
4. Connect the electric system connector (2)
5. Switch on the motor (see "Start-up and acceleration")
6. After warming up the motor, accelerate until all the green voltage control
LEDs light up on the instrument panel (5). If they flash, this means the
motors are being checked
7. The LEDs of the motor control (4) will flash at the same time
8. Press the suction motor switch (1)
9. Press the cylindrical brush motor switch (2)
10. Press the solenoid valve switch (3)
11. Press the brush motor switch (4)
12. Position the two-way switches (1 and 2) on automatic
13. Turn the lever (3) anticlockwise to turn on the tap. The water indicator light
(4) only switches on during the advance phase
14. Check the parking brake is released (1)
15. Position the selector on (1) forwards
16. Select the advance speed by turning the knob (2)
