5
SYMBOLS USED ON THE MACHINE
Symbol denoting solenoid valve open
Used to indicate the solenoid valve switch
The indicator light showing that the solenoid valve is open
Symbol denoting empty solution tank
Symbol denoting full recovery tank
Symbol denoting squeegee fully down
Symbol denoting squeegee rise/fall
The indicator light showing that the jack is working
Symbol denoting cylindrical brush fully down
Symbol denoting rise/fall of cylindrical brush base
The indicator light showing that the jack is working
Symbol denoting sideways movement of brush base
The indicator light showing that the jack is working
Symbol denoting end stop of base sideways movement
The green indicator light comes on when the brush base is fully to the left
