7
SYMBOLS USED ON THE MACHINE
Symbol denoting the cylindrical brush lever, and the squeegee
Sideways movements of the lever are accompanied by vertical movements of the squeegee. Longitudinal
movements of the lever are accompanied by vertical movements of the cylindrical brush
base.
Symbol denoting pressure applied to the brushes
Symbol denoting tap regulation
3
2
1
Symbol denoting forwards and backwards speed selector
Symbol denoting motor control
Symbol
Generator symbol
Oil pressure symbol
Symbol denoting the temperature of the cooling water
