1-2 Taking a Look at the Computer
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: J Abercrombie Saved date: 04/26/00 3:59 PM
Part Number: 140075-002 File name: Ch01
Top Components Continued
Component Function
3
Stereo speakers Built-in speakers for high-quality
stereo sound and a multimedia
sound system.
4
Battery light Indicates the battery is charging
when light is on. If the light is off, the
battery is not charging. A blinking
light indicates a low battery condition.
5
Power/Suspend light Blinks every four seconds. This
indicates the computer is in suspend
mode.
6
Volume Control buttons Controls the speaker volume.
7
MultiBay Accepts a CD drive, DVD drive,
SuperDisk LS-120 drive, second hard
drive, third battery pack, or a weight
saver.
8
Speaker ports Integrated tuned loudspeaker ports
that allow airflow to and from the
internal stereo speakers.
9
TouchPad Provides integrated pointing device
functions.
Left and right TouchPad
buttons
or
Function like the left-click and right-
click buttons of an external mouse.
Used with the TouchPad, the
TouchPad button drags and
highlights.
Pointing Stick Moves the mouse cursor.
Left and right pointing
stick buttons (pointing
stick models only)
Functions like the left-click and right-
click buttons on an external mouse.
:
DualBay Accepts a diskette drive, a second
battery pack, or a weight saver.
q
Easy Access buttons Allows direct access to predefined
websites when connected to the
Internet.
