1-4 Taking a Look at the Computer
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: J Abercrombie Saved date: 04/26/00 3:59 PM
Part Number: 140075-002 File name: Ch01
Right Side Components
Right Side Components
Component Function
1
PC Card slots Slots that support Type II or Type III
PC Cards, such as modem, hard
drive, or network cards. These slots
accept 16-bit PC Cards and 32-bit
Cardbus Cards.
2
Microphone jack Connects to an external microphone.
3
Stereo speaker/
headphone jack
Connects to a headphone or external
speakers.
4
Lock provision Accepts an anti-theft cable that
secures the computer to a fixed
object.
5
RJ-45 jack Connects the Ethernet cable (NIC) to
the computer. Available on models
with an internal NIC/modem
combination
6
RJ-11 jack Connects the RJ-11 modem cable to
the computer. Available on models
with an internal modem
Continued
To Next Page
