Upgrading the Computer 11-3
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: J Abercrombie Saved date: 04/26/00 4:31 PM
Part Number: 170045-002 File name: Ch11
5. Insert the memory expansion board into the empty memory
expansion slot
1
at a 45-degree angle. Then slide it gently into
place until it is seated while tilted.
NOTE: A memory expansion board is asymmetrically keyed
(notched) to ensure correct positioning.
6. Push the memory expansion board down
2
until the retention
clips snap back into place.
!
WARNING: To reduce the risk of electrical shock, fire, or damage to
the equipment, do not turn on the computer or reconnect any
external cables during this step.
7. Replace the keyboard.
8. Reconnect external cables and turn on the computer.
