To load a script file for Lotus cc:Mail or a Lotus Notes version
earlier than 4.x— Use the installation procedures in your Lotus
documentation. The script files for these applications are at
C:\Program Files\Compaq\CPQLANModem\Modem\Scripts.
■ If you are using Lotus cc:Mail, select script file
cc56kcom.mdm.
■ If you are using a Lotus Notes version earlier than 4.x,
select script file LN56kcom.mdm.
To load a script file for Lotus Notes version 4.x or later—
1. In Windows Explorer select C:\Program Files\Compaq\
CPQLANModem\Modem\Scripts.
2. Copy the LN56kcom.mdm file in the Scripts folder to the
Notes\Data\Modems folder.
3. Open the Lotus Notes application.
4. From the menu bar, select FileÅToolsÅUser
PreferencesÅPorts icon.
5. Make sure the Port Enabled checkbox is selected.
6. Make sure the modem COM port selected is COM2.
7. Select the COMx Options button.
8. From the Modem Type list in the Additional Setup dialog
box, select Compaq 56K (V.90) Mini PCI Card.
9. Make sure that Hardware Flow Control is selected and the
following options are set:
■ Maximum port speed—115200.
■ Port number—COM2.
10. To confirm your settings and close the Additional Setup
dialog box, select OK.
