Compaq Deskpro 2000 Service & Reference Guide

Compaq Service Reference Guide G-1
appendix
G
S
YSTEM
B
OARD AND
R
ISER
B
OARD
R
EFERENCE
D
ESIGNATORS
Designator Component
E49 Clear Password header
E50 CMOS header
E51 Video pass through header
J6 BNC
J7 RJ-45 Jack
J8 IEEE 1394
J10 - 19 ISA slots
J20 -29 PCI slots
J30 Riser board socket
J31 - J35 Device bay connectors
J36 AC97 connector
J40 AGP slot
J50 First parallel port
J51 Second parallel port
J52 Double-stacked parallel port
Top Port B
Bottom Port A
J66 Keyboard connector (Closest to monitor connector)
J67 Mouse connector
J68 Double-stacked mouse/keyboard connector
Top Mouse
Bottom Keyboard
J69 Video connector
J70 Single USB connector
J71 Double-stacked USB
Top Port 1
Bottom Port 2
J72 Microphone jack
J73 Line-in jack
J74 Line-out jack
J75 Headphone jack
J76 Volume control
Continued

Compaq Deskpro 2000 Specifications

General

Brand	Compaq
Model	Deskpro 2000
Category	Desktop
Language	English
