Compaq Service Reference Guide G-3
Reference Designators
Continued
Designator Component
P100 ITP connector
P216 White box chassis fan
SW1 Processor speed switch
SW2 Security hood switch
SW50 Clear CMOS switch
XBT1 Battery socket
XMM1 Memory slot. The first slot populated (DIMM1 or RIMM1) and tested.
XMM2 - XMM5 Following memory slots
XU1 Primary processor socket
XU2 Secondary processor socket
XU15 ROM socket
