Accessing DIMM Sockets on the
System Board
WARNING: Before removing the top panel, ensure that the
computer is turned off and that the power cord is disconnected
from the electrical outlet.
To reduce the risk of personal injury from hot surfaces, allow
the internal system components to cool before touching them.
CAUTION: To prevent loss of data or damage to the
equipment, place the system in STANDBY before removing the
side access panel. When this panel is removed, the power
supply is disabled until the panel is properly replaced.
1. Loosen the thumbscrew.
2. Slide the top access panel towards the rear of the unit about 2 inches and
lift away from the unit.
Figure 4-19.
Removing the side panel
