Figure 4-22.
Installing a SCSI drive
IMPORTANT: If the drive cage is configured for simplex mode (Pass-
Thru board installed) and you are using 1-inch drives, do not use drive bay
7 (see Figure 4-25). If you install a drive in bay 7, the service LED for that
drive will light and the drive will be inaccessible.
