Troubleshooting l 6-33
Replacing the Heaters
Regeneration Heater Tube
(continued)
9 Connect the hose and clamp to the bottom of the new regeneration heater
tube.
10 Put the original insulation back on the regeneration heater tube. Apply
duct tape to the seam that was cut during removal.
11 Connect the heater wires and high temperature switch wires to the quick
disconnects near the heater tube.
12 Replace the side panel of the dryer.
13 Make sure the regeneration heater fuses are not blown before applying
power to the new heater.
6
Troubleshooting
